M6/ 6mm, Brolly Fixings, Cavity Wall Fixings.
M6/ 6mm, Heavy Duty Plasterboard/ Drywall Cavity Fixing, Wall Anchors, Brolly Fixings.
Here at Fixaball, we stock all sizes and lengths at the best internet prices and free delivery
Orders placed before 2pm are usually dispatched same day (Mon-Fri).
Please make your size and pack quantity selection from the drop down menus at the top of the page.
- Suitable for fixing to most cavity wall situations.
- Fixing can be set in position either by using the spring loaded setting tool or by tightening and removing the screw.
- Combination screw head to accept both slot or pozi drivers.
- 2 anti-rotation teeth prevent the anchor from spinning.
- Strengthened anchor wings give maximum load capacity.
Directions
Drill hole with appropriate drill bit. Insert anchor ensuring that points on the shoulder enter the face of the plasterboard. Tighten screw to set the anchor legs in position. Remove the screw. Align fixture and replace screw until tight
Available with 3 screw diameters; M4, M5 or M6.
- M4 - 9mm hole
- M5 - 11mm hole
- M6 - 15mm hole.
|
Brolly Fixings – All Measurements in mm |
||
|
Sizes |
Wall Thickness |
Screw Length |
|
M4x38 |
8-16 |
45 |
|
M4x45 |
16-23 |
50 |
|
M4x60 |
31-38 |
65 |
|
M5x37 |
6-13 |
45 |
|
M5x52 |
7-16 |
60 |
|
M5x65 |
17-32 |
70 |
|
M6x52 |
7-16 |
60 |
|
M6x65 |
17-32 |
70 |
Image is for illustrative purposes only.
These are not mixed packs.
