No. 6 (3.5mm), Pozi, Pan, Self-Tapping Screws, A Point, A2 Stainless.
No. 10 - 4.8mm, Self-Tapping Screws, Pozi, Pan, A Point, A2 Stainless Steel.
Fixaball.co.uk sells no. 10, stainless self tappers, at the best internet prices, with free, first class delivery.
Orders placed before 2pm are usually dispatched same day (Mon-Fri).
Please make your size and pack quantity selection from the drop down menus.
Gauges Available and equivalent in Metric (mm)
No. 2 - 2.2mm
No. 4 - 2.8mm
No. 6 - 3.5mm
No. 8 - 4.2mm
No. 10 - 4.8mm
No. 12 - 5.5mm
No. 14 - 6.1mm
No.16 - 6.8mm
Screws that Self-Tap
A self tapping screw is a screw that can tap its own hole as it is driven into the material. For hard substrates such as metal or hard plastics, the self-tapping ability is often created by cutting a gap in the continuity of the thread on the screw, generating a flute and cutting edge similar to those on a tap. Thus, whereas a regular machine screw cannot tap its own hole in a metal substrate, a self-tapping one can (within reasonable limits of substrate hardness and depth)
Self-Tapping Screw Head types
Pozidrive (pozi), Countersink (csk) Heads – Sits flush with the material surface.
Pozidrive (pozi), Pan Heads – Sits proud of the material.
Pozidrive (pozi), Flange Heads – Sits proud of material, spreading the load with an extended flange.
Self-Tapping Screw Materials
We stock Zinc plated self-tapping screws for general use (internal) and A2 stainless steel for improved corrosion resistance (external use).
Important Dimensions (sizes)
No.6 = screw dia. 3.5mm, head dia. 8m, head height 2.1mm.
No.8 = screw dia. 4.2mm, head dia. 9.8mm, head height 2.3mm.
No.10 = screw dia. 4.8mm, head dia. 11.2mm, head height 3mm.
No.12 = screw dia. 5.5mm, head dia. 12.8mm, head height 3mm.
All screw lengths are measured from the underside of the head.
Image is for illustrative purposes only.
